Epson PowerLite 84 User Manual

3
-
Contents
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Using Your Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Getting More Information . . . . . . . . . . . . . . . . . . . . . . . . 8
Registration and Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Unpacking the Projector. . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Projector Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Additional Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Optional Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1
Displaying and Adjusting the Image . . . . . . . . 15
Positioning the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Turning the Projector On and Off . . . . . . . . . . . . . . . . . . . . 17
Turning On the Projector . . . . . . . . . . . . . . . . . . . . . . . 18
Using the Direct Power On Function . . . . . . . . . . . . . . 19
Shutting Down the Projector . . . . . . . . . . . . . . . . . . . . . 20
Selecting the Image Source . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Troubleshooting Display Problems. . . . . . . . . . . . . . . . . . . . 21
You Can’t Project an Image . . . . . . . . . . . . . . . . . . . . . . 21
The Projector and Notebook Don’t Display
the Same Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Adjusting the Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Adjusting the Height of Your Image . . . . . . . . . . . . . . . 24
Focusing and Zooming Your Image . . . . . . . . . . . . . . . . 24
Adjusting the Image Shape. . . . . . . . . . . . . . . . . . . . . . . 25
Correcting Computer Images. . . . . . . . . . . . . . . . . . . . . 27

Epson PowerLite 84 Specifications

General

Projection technology	LCD
Contrast ratio (typical)	2000:1
Projector native resolution	XGA (1024x768)
Aspect ratio	4:3
Dimensions (WxDxH)	327.6 x 248.9 x 93.9 mm
Power requirements	100-240VAC +/-10%, 50/60Hz AC
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	6000 h
Focal length range	18.2 - 29.2 mm
RMS rated power	10 W
Number of built-in speakers	1
Microphone in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	2
Power consumption (typical)	289 W
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Weight	3100 g
