Epson PowerLite 84 User Manual

Using the Remote Control 33
Zooming Part of Your Image
You can zoom in on a portion of the image using the E-Zoom buttons
on the remote control.
1. Press the
E-Zoom button on the remote control.
You see a crosshair indicating the center of the zoom-in area.
2. Use the pointer buttons to position the crosshair.
3. Continue pressing the
E-Zoom button to enlarge the selected
area up to 4× magnification.
4. While the image is enlarged, you can:
■ Use the pointer buttons to move around the screen.
■ Press the E-Zoom button to zoom out.
5. When done, press the
ESC button to return the image to its
original size.
Controlling the Volume
To change the volume, press the or button on the remote
control or projector.
You can also adjust the volume using the projector’s menu system. See
page 68.
note
To temporarily shut off the
sound and picture, press the
A/V Mute button or close
the A/V Mute slide.

Epson PowerLite 84 Specifications

General

Projection technology	LCD
Contrast ratio (typical)	2000:1
Projector native resolution	XGA (1024x768)
Aspect ratio	4:3
Dimensions (WxDxH)	327.6 x 248.9 x 93.9 mm
Power requirements	100-240VAC +/-10%, 50/60Hz AC
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	6000 h
Focal length range	18.2 - 29.2 mm
RMS rated power	10 W
Number of built-in speakers	1
Microphone in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	2
Power consumption (typical)	289 W
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Weight	3100 g
