128
Appendix
Printable Ar
ea
40 mm wide paper
58 mm wide paper
80 mm wide paper
39.5 ± 0.5 mm
35.0 mm (280 dots)
2.15 mm
(2.35 mm)
0.125 mm
Dot No. 280
Dot No. 1
0.125 mm
57.5 ± 0.5 mm
52.5 mm (420 dots)
2.65 mm
2.35 mm
Dot No. 420
Dot No. 1
79.5 ± 0.5 mm
72 mm (576 dots)
2.65 mm
(4.85 mm)
Dot No
. 576
Dot No
. 1
0.125 mm
127
129
