130
Appendix
When the paper removal detector is enabled (with backfeed)
When the paper removal detector is enabled, the top margin can be changed by feeding paper backward.
Built-in Memory
Electrical Specifications
*1: Average power consumption measured under our operating conditions. It varies depending on the conditions of use and the
model.
Receive buffer 4 KB
Area for downloaded characters 12 KB (also used for downloaded bit images)
Area for macro 2 KB
Area for NV graphics 384 KB
Area for downloaded graphics 208 KB
Area for user NV memory 1 KB
Power supply PS-190 (power supply with the AC adapter)
Operating voltage DC 24 V
Current consumption
(24V, 25°C, standard print
density)
Operating Approx. 1.8 A on average
* When print ratio is approximately 18%
* Font A
* 48 characters mode
* Printing ASCII characters (repeating 20h to 7Fh) in 30 lines +
paper feed 5 lines + Autocut
Standby Approx. 0.1 A on average
AC power consumption*1
(100 - 230 V/50 - 60 Hz)
Operating Approx. 31.3 W
Standby Approx. 1.6 W
Autocut position
Approx.
14.0 mm
Paper feed direction
Center of the print head
Approx.
5.0 mm
Print start position
