53
EN
MIG/MAG standard synergic welding
General The MIG/MAG standard synergic welding process is only available in combination with the
Synergic control panel.
MIG/MAG stand-
ard synergic
welding
On the Synergic control panel:
Press the "Material" button to select the filler metal used.
Assignment of the SP position depends on the welding database used for the power
source.
Press the "Wire diameter" button to select the diameter of the wire electrode used.
Assignment of the SP position depends on the welding database used for the power
source.
Press the "Shielding gas" button to select the shielding gas used.
Assignment of the SP position depends on the welding database used for the power
source.
Press the "Process" button to select the desired welding process:
MIG/MAG standard synergic welding
Press the "Mode" button to select the desired MIG/MAG mode:
2-step mode
4-step mode
Special 4-step mode
If they were not set via a robot interface, press the "Parameter selection" buttons to
select the desired welding parameters to be used to specify the welding power:
Sheet thickness
Welding current
Wire feed speed
Welding voltage
Use the appropriate adjusting dial to set the relevant welding parameters.
The welding parameter values are shown in the digital display located above them.
All welding parameter set values remain stored until the next time they are changed. This
applies even if the power source is switched off and on again in the meantime.
IMPORTANT! Under certain circumstances, welding parameters that have been set
on a control panel of a system component (TR 2000 and TR 3000 remote controls or
robot interface) may not be changed on the control panel of the power source.
1
2
3
4
5
6
7
