MIG/MAG standard manual welding
General The MIG/MAG standard manual welding process is a MIG/MAG welding process with no
synergic function.
Changing one parameter does not result in any automatic adjustments to the other param-
eters. All of the variable parameters must therefore be adjusted individually, as dictated by
the welding process in question.
Available parame-
ters
The following parameters are available in MIG/MAG manual welding:
Wire feed speed
1 m/min (39.37 ipm) - maximum wire feed speed, e.g. 25 m/min (984.25 ipm)
Welding voltage
TSt 3500: 15.5 - 31.5 V
TSt 5000: 14.5 - 39 V
Dynamic
... for influencing the short-circuiting dynamic at the moment of particle transfer
Welding current
Only for displaying the actual value
MIG/MAG stand-
ard manual weld-
ing
Press the "Process" button to select the desired welding process:
MIG/MAG standard manual welding
Press the "Mode" button to select the desired MIG/MAG mode:
2-step mode
4-step mode
In MIG/MAG standard manual welding, special 4-step mode corresponds to conventional
4-step mode.
Press the "Parameter selection" button to select the wire feed speed parameter
Use the adjusting dial to set the desired value for the wire feed speed
Press the "Parameter selection" button to select the welding voltage parameter
Use the adjusting dial to set the desired value for the welding voltage
The welding parameter values are shown in the digital display located above them.
All welding parameter set values that have been set using the adjusting dial remain stored
until the next time they are changed. This applies even if the power source is switched off
and on again in the meantime.
To display the actual welding current during welding:
- Press the "Parameter selection" button to select the welding current parameter
- The actual welding current is shown on the digital display during welding.
IMPORTANT! Under certain circumstances, welding parameters that have been set on a
control panel of a system component (TR 2000 and TR 3000 remote controls or robot in-
terface) may not be changed on the control panel of the power source.
