Open the gas cylinder valve

Set the shielding gas flow rate:

If there is a "Gas test" button:

- Press and release the "Gas test" button

- Turn the adjusting screw on the underside of the pressure regulator until the pres-

sure gauge shows the required gas flow rate

- Press and release the "Gas test" button again

If there is no "Gas test" button:

- Press the "Mode" button to select 4-step mode

- Set the "Ito" parameter to "Off" in the Setup menu

- Disengage the feed rollers

- use the robot to set the welding start-up or gas test signal

- turn the adjusting screw on the underside of the gas pressure regulator until the

pressure gauge shows the required shielding gas flow rate

- cancel the welding start-up or gas test signal

- engage the feed rollers

use the robot to set the welding start-up signal and initiate welding

Corrections dur-

ing welding

To obtain the best possible welding results, the arc-force dynamic parameter will some-

times need to be adjusted.

Press the "Parameter selection" button to select the arc-force dynamic parameter

Use the adjusting dial to set the desired arc-force dynamic value

The welding parameter value is shown in the digital display located above it.

CAUTION! Risk of injury and damage from electric shock and from the wire

electrode emerging from the torch. If the welding start-up signal is set:

- keep the welding torch away from your face and body

- do not point the welding torch at people

- make sure that the wire electrode does not touch any conductive or

earthed parts, such as the housing, etc.
