Configuration of Encryption using IPsec
415
Encryption and Digital Signature Settings
13
Important • You cannot import a certificate that has been already registered in [Local Device] or [Others]. Delete
the registered certificate before importing.
• If the certificate to be imported contains the V3 extension "keyUsage", "digitalSignature" must be
asserted.
1) Click the [Properties] tab.
2) Click [Security] to display the items in the folder.
3) Click [Machine Digital Certificate Management].
4) Click [Upload Signed Certificate].
5) Enter [Password].
6) Enter [Retype Password].
7) Enter a file name you want to import or select a file to import from a dialog box
displayed by clicking the [Browse] button, and then select [Save].
8) Click the [Import] button.
9) Refresh the web browser.
3 Configure the certificate.
1) Click [Security].
2) Click [Certificate Management].
3) Select [Local Device] for [Category] and [IPsec] for [Certificate Purpose], and then click
the [Display the list] button.
4) Select the check box next to the certificate to set.
5) Click the [Certificate Details] button.
6) Click the [Use this certificate] button.
7) Click [Reboot Machine]. The machine reboots and the settings are enabled.
Step2 Configuration on the Machine (Configuration of IPsec)
The following describes configuration procedures to set up IPsec on the machine.
1 Press the <Log In/Out> button.
2 Enter the system administrator's user ID with the numeric keypad or the keyboard
displayed on the screen, and select [Enter].
When a passcode is required, select [Next] and enter the system administrator's passcode,
and select [Enter].
Note • The default user ID is "11111".
• The default passcode is "x-admin".
3 Select [Tools] on the Services Home screen.
4 Select [Connectivity & Network Setup].
5 Select [Security Settings].
6 Select [IPsec Settings].
7 Configure the required settings.
For details on the settings, refer to "IPsec Settings" (P.241).
8 Select [Close].
To Next Page
