3 Copy
140
Copy
3
You can specify a value in the range from 0 to 356 mm for the width (X) and the length (Y)
in 1 mm increments.
Note •Specify the 2 coordinates from the top right corner of the document.
• When specifying multiple areas, the specified areas can overlap each other.
• When [Reduce/Enlarge] is set, the specified area will be reduced or enlarged accordingly.
1 Select [Area 1], [Area 2], or [Area 3].
2 Select the text box for [X1], and enter the value
for X1 using the numeric keypad.
3 Select the text box for [Y1], and enter the value
for Y1 using the numeric keypad.
4 Select the text box for [X2], and enter the value
for X2 using the numeric keypad.
5 Select the text box for [Y2], and enter the value for Y2 using the numeric keypad.
Note •If all of [X1], [Y1], [X2], and [Y2] are set to [0], the area will be invalid. If no other area is specified, the
Delete Outside/Delete Inside feature cannot be used.
• Pressing the <C (Clear)> button clears the value you have entered.
Clear Area 1 (Area 2 or Area 3)
Clears all the values set for Area 1 (Area 2 or Area 3).
Stored Programming (Calling a Stored Program for Build Job)
This feature allows you to call a stored program for Build Job.
This feature is the same as "8 Stored Programming" > "Calling a Stored Program" > "Calling
a Stored Program for Build Job".
For more information, refer to "Calling a Stored Program for Build Job" (P.337).
To Next Page
