6. SYSTEM DESIGN
SYSTEM DESIGN1.
SYSTEM OUTLINE1-1.
: Transmission line [O.U. - B.B.(primary)] ( )
: Transmission line [B.B.(primary) - B.B.(secondary)] ( )
: Central remote controller line [Central remote controller - B.B.] ( )
: Power supply and Transmission line [B.B. - I.U.] ( )
: Power supply [Outdoor Unit] ( )
: Power supply [Branch Box] ( )
: Remote controller line [I.U. - R.C.] ( )
: Piping ( )
Outdoor unit
Indoor units
Branch box 1
(Primary)
Central
remote
controller
Branch box 2
(Secondary)
Branch box 3
(Secondary)
Earth leakage
breaker
Power
supply
Circuit breaker
(over current)
Earth leakage
breaker
Power
supply
Circuit breaker
(over current)
Earth leakage
breaker
Power
supply
Circuit breaker
(over current)
Power
supply
Earth leakage
breaker
Circuit breaker
(over current)
- (06 - 01) -
