6. SYSTEM DESIGN
WIRING DESIGN4.
ELECTRICAL WIRING4-1.
PRECAUTION FOR ELECTRICAL WIRING

Regulation on wire diameter and selecting circuit breaker size differ from locality.
Install in accordance with local rules and regulations.
Warning
Do not turn on the power until all installation work is complete.îž”
Before starting work, check that power is not being supplied to the unit.îž”
Connect the connection cable firmly to the terminal board. Imperfect installation may cause a fire.îž”
Always fasten the outside covering of the connection cable with the cord clamp. (If the insulator is îž”
chafed, electric leakage may occur.)
Make sure to install Earth leakage breaker. Otherwise, it may cause electric shock or a fire.îž”
Always connect the ground wire.îž”
Never install a condenser for improving the power factor. (It will not improve the power factor and îž”
the condenser will become extremely hot.)
- (06 - 38) -
