3. OUTDOOR UNIT & BRANCH BOX
SAFETY DEVICES9.
OUTDOOR UNIT9-1.
Safety device AO
îš¾
G45LBT8
Fuse
Main PCB AC 250V 3.15A
INV PCB DC 400V 5A
Filter
AC 250V 10A
AC 250V 3.15A
Protector Filter AC 500V 50A
Compressor Protector
Overcurrent protection -
Temperature protection Off : 115°C On : 70°C
High Pressure Protection Off : 4.2MPa On : 3.2MPa
Low Pressure Protection Off : 0.05MPa
BRANCH BOX9-2.
Safety device UTP-PY03A, UTP-PY02A
Fuse PCB
AC 250V 3.15A x 2
AC 250V 10A x 1
- (03 - 20) -
