2. MODEL SELECTION
SLIM DUCT TYPE6-2-2.
MODEL : AR
 
G07LLTA
Outdoor Temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 24.0 26.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 1.92 1.74 1.59 1.43 1.23
-10.0 -11.0 2.15 1.95 1.78 1.60 1.38
-5.0 -7.0 2.39 2.17 1.98 1.78 1.53
0.0 -2.0 2.61 2.37 2.16 1.94 1.67
5.0 3.0 2.79 2.54 2.32 2.08 1.79
7.0 6.0 2.86 2.60 2.37 2.13 1.84
10.0 8.0 2.86 2.60 2.37 2.13 1.84
15.0 10.0 2.86 2.60 2.37 2.13 1.84
20.0 15.0 2.86 2.60 2.37 2.13 1.84
MODEL : AR
 
G09LLTA
Outdoor Temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 24.0 26.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 2.42 2.20 2.00 1.80 1.55
-10.0 -11.0 2.71 2.46 2.24 2.02 1.74
-5.0 -7.0 3.01 2.74 2.49 2.24 1.93
0.0 -2.0 3.29 2.99 2.72 2.45 2.11
5.0 3.0 3.53 3.21 2.92 2.63 2.26
7.0 6.0 3.61 3.28 2.99 2.69 2.32
10.0 8.0 3.61 3.28 2.99 2.69 2.32
15.0 10.0 3.61 3.28 2.99 2.69 2.32
20.0 15.0 3.61 3.28 2.99 2.69 2.32
MODEL : AR
 
G12LLTA, AR

G12LLTB
Outdoor Temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 24.0 26.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 3.20 2.91 2.65 2.39 2.06
-10.0 -11.0 3.58 3.26 2.97 2.67 2.30
-5.0 -7.0 3.99 3.63 3.30 2.97 2.56
0.0 -2.0 4.35 3.96 3.61 3.24 2.80
5.0 3.0 4.67 4.25 3.87 3.48 3.00
7.0 6.0 4.78 4.35 3.96 3.56 3.07
10.0 8.0 4.78 4.35 3.96 3.56 3.07
15.0 10.0 4.78 4.35 3.96 3.56 3.07
20.0 15.0 4.78 4.35 3.96 3.56 3.07
MODEL : AR
 
G14LLTA, AR

G14LLTB
Outdoor Temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 24.0 26.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 3.88 3.53 3.22 2.89 2.49
-10.0 -11.0 4.35 3.95 3.60 3.24 2.79
-5.0 -7.0 4.83 4.40 4.00 3.60 3.10
0.0 -2.0 5.28 4.80 4.37 3.93 3.39
5.0 3.0 5.66 5.15 4.69 4.22 3.63
7.0 6.0 5.79 5.27 4.80 4.32 3.72
10.0 8.0 5.79 5.27 4.80 4.32 3.72
15.0 10.0 5.79 5.27 4.80 4.32 3.72
20.0 15.0 5.79 5.27 4.80 4.32 3.72
HEATING CAPACITY
TC : Total Capacity kW.
The data is based on the following conditions.
Pipe length : 5m [Outdoor unit - Branch box], 3m [Branch box - Indoor unit]
Height difference : 0m [Outdoor unit - Indoor unit].
- (02 - 30) -
MODEL SELECTION MODEL SELECTION
