6. SYSTEM DESIGN
Caution of wiring method
ote the connection between branch bo enough according to the gure beow.
OUTDOOR UNIT
or BRANCH BOX
(INPUT)
BRANCH BOX 1
(OUTPUT)
BRANCH BOX 1
(OUTPUT)
BRANCH BOX 1
(OUTPUT)
BRANCH BOX 2
(OUTPUT)
BRANCH BOX
BRANCH BOX 2
(SECONDARY 1)
BRANCH BOX 3
(SECONDARY 2)
BRANCH BOX 1
(PRIMARY)
: Cable line
BRANCH BOX 2
(OUTPUT)
BRANCH BOX 2
(OUTPUT)
OUTDOOR UNIT
or BRANCH BOX
(INPUT)
OUTDOOR UNIT
or BRANCH BOX
(INPUT)
Connection prohibited
Connection prohibited
OUTDOOR UNIT
- (06 - 46) -
SYSTEM
DESIGN
SYSTEM
DESIGN
