6. SYSTEM DESIGN
MODEL: UTY-RNN5-4-1.
M
SWITCHING SELECTION OF FUNCTION SETTING MODE
2) To activate the function setting mode, hold down the three buttons "SET TEMP. V", "SET
P. and at the sae tie or seconds or onger.
Function setting mode initial display
BUTTON NAME AND FUNCTION
During address setting mode, indoor unit will reject any operation command from the remote
controller.
Function number
Refer to FUNCTION DETAILS
Remote controller address
Fixed to 00.
Set Time “<” and “>” button
Switches the function number.
Setting number
Refer to FUNCTION DETAILS
SET TEMP. “V” and “
” button
Switches the setting number.
TIMER SET button
Transmits function setting
- (06 - 74) -
SYSTEM
DESIGN
SYSTEM
DESIGN
