Fujitsu CELSIUS W380 User Manual

System upgrades
Installing and removing a board
!
Please take note of the section "
Information about boards".
When installing new boards, make sure that they do not interfere with existing boards.
The number, position and arrangement of the board slots on the mainboard can be found in the
manual for the mainboard. Boards may already be installed on shipment.
Installing a board
► Open the casing (see "Opening the casing").
► Fold up the drive cage (see "
Opening the drive cage").
1
2
► Press on the curved part of the retaining clip (1).
► Pull the slot cover out of the slot in the direction of the arrow (2).
Do not throw away the slot cover. For cooling, protection against fire and in order to
comply with EMC regulations, you must refit the slot cover if you remove the board.
i
40 Fujitsu Technology Solutions
