Fujitsu CELSIUS W380 User Manual

System upgrades
Removing boards
► Open the casing (see "Opening the casing").
► Fold up the drive cage (see "
Opening the drive cage").
► Disconnect the cables connected to the board.
1
2
► Press on the curved part of the retaining clip (1).
► If you have also secured the board with an additional screw, remove the screw now.
► Pull the board out of the slot in the direction of the arrow (2).
► Place the board into appropriate packaging.
For cooling, protection against fire, and in order to comply with EMC (electromagnetic
compatibility) regulations, you must refit the slot cover.
!
2
1
► Push the slot cover into the slot (1).
42 Fujitsu Technology Solutions
