System upgrades
Installing an accessible drive
► Open the casing (see "Opening the casing").
► If a slide-in module is fitted, remove this first. To do this, proceed in the same way as when
removing an accessible drive (see "
Removing an accessible drive").
!
Do not dispose of the empty slide-in module. For cooling, protection against fire, and in
order to comply with EMC regulations, you must refit the empty slide-in module if you
remove the drive again later.
► Adjust the required settings on the drive (if necessary, on already-installed drives as well).
2
1
► Slide the accessible drive into the casing as far as the stop (1).
► Plug the data and the power supply connectors into the drive. Make sure the polarity is correct.
► Press on the retaining clip (2) and, at the same time, slide it up slightly.
► Close the casing (see "
Closing the casing").
It may be necessary to modify the entry for the drive in the
BIOS Setup.
i
Fujitsu Technology Solutions 47
