Clearing the Password
Clear the password in the following procedure.
1 Right-click the Software Operation Panel icon in the
taskbar, and select [Password Setting] from the menu.
D The [Password setting] dialog box appears.
2 Enter the password and click the [OK] button.
D The [Password setting] dialog box appears.
3 Leave both fields blank and click the [OK] button.
D A message dialog box appears.
4 Click the [OK] button.
D The password is cleared.

Fujitsu fi-6110 Specifications

General

Film scanning	No
Color scanning	Yes
Grayscale levels	1024
Input color depth	24 bit
Maximum scan size	216 x 355.6 mm
Optical scanning resolution	600 x 600 DPI
Flatbed scan speed (b/w, A4)	3 sec/page
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	500 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	52 - 127 g/m²
Dimensions (WxDxH)	292 x 143 x 130 mm
Power requirements	100 - 240 V, 50/60 Hz
Image formats supported	JPG, TIF
Recommended media weight	80 g/m²
Compatible operating systems	Microsoft Windows 7 (32bit/64bit)/Vista (32bit/64bit), Windows Server 2003/2008/2008 R2 (32bit/64bit), Windows XP (32bit/64bit).
Power supply type	AC
Power consumption (standby)	5.36 W
Power consumption (typical)	28 W
Operating temperature (T-T)	42 - 95 °F
Operating relative humidity (H-H)	20 - 80 %
Bundled software	TWAIN, ISIS, ScandAll PRO, Adobe Acrobat, QuickScan Pro.

Weight and Dimensions

Depth	143 mm
Width	292 mm
Height	130 mm
Weight	3000 g
