Removing a Color from the Scanned Image
[Dropout color]
With "Dropout color", you can select either green, red, or blue
(primary colors) to remove the details of the selected color
from a scanned image.
For example, if a document with black characters and a green
background is scanned, only the black characters will appear
on the scanned image if [Green] is selected.
1 Start up the Software Operation Panel.
Refer to "9.1 Starting Up the Software Operation Panel" (page 125).
2 From the listing on the left, select [Device Setting 2] J
[Dropout color].
3 Select a color to drop out.
Red, Green, Blue: Red, green, or blue is dropped out.
None: No color is dropped out.
Dropout works the best with light (low density) colors, and dark
colors may not drop out.
Dropout color is only available in black & white or grayscale
mode.
The Software Operation Panel allows you to choose the
color from red, green, and blue only. To drop out a color of
your choice, configure the setting from the scanner driver.
For more details, refer to "Removing a Color from the
Scanned Image (Dropout Color)" (page 59).
With TWAIN driver, this setting can also be configured
from the scanner driver's setup dialog box. Note that
priority is given to the scanner driver setting.
With ISIS driver, the scanner driver setting is enabled at
all times.
