Fujitsu PRIMERGY RX4770 M6 User Manual

Figure 60: Installing the 2.5-inch HDD/SSD module
▶
Insert the HDD/SSD module into a drive bay and carefully push back as far
as it will go (1).
▶
Close the locking lever in the direction of the arrow until it engages (2).
▶
When using a RAID array
, add the additional HDD/SSD to the RAID array
.
Configuring the RAID array, see the documentation of the RAID
controller, used in your configuration, see "Documentation overview" on
page 26.
Concluding steps
▶
If applicable, "Installing the front cover with lock" on page 61.
Hard disk drive (HDD) / solid state disk (SSD)
144 Upgrade and Maintenance Manual RX4770 M6
