4.10.2 Removing a riser module
Figure 20: Removing a riser module (example: riser module for PCIe slot 1 and slot 2)
▶
If necessary
, disconnect the cables from the other components.
▶
Carefully pull out the corresponding riser module upward by holding it at the
four touch points (see circles).
4.10.3
Installing a riser module
Figure 21: Installing a rise rmodule (example riser module for PCIe slot 1 and slot 2)
Basic hardware procedures
RX4770 M6 Upgrade and Maintenance Manual 63
