Fujitsu PRIMERGY RX4770 M6 User Manual

▶
"Getting access to the component" on page 48
.
▶
Remove the riser modules, see "Removing a riser module" on page 63.
▶
"Removing the fan cage" on page 64.
▶
"Removing the air duct" on page 68.
▶
"Removing the top system board carrier" on page 73.
▶
"Removing the OCP air duct" on page 70.
Installing the M.2 SSD
CAUTION
An M.2 SSD in M.2 slot 2 is not recognized, if M.2 slot 1 is free.
▶
The M.2 slot 1 must be equipped first.
To support different length of M.2 SSD, the M.2 SSD latch can be
moved to another position.
System board and components
RX4770 M6 Upgrade and Maintenance Manual 353
