Fujitsu ScanSnap S500 User Manual

2.2 Connecting ScanSnap to your PC
ScanSnap S500 Operator's Guide 23
Connecting ScanSnap
2
■ Connecting the USB Cable
Connect the USB cable as shown below.
Operation
1. Remove the seal on the rear side of ScanSnap.
2. Insert the USB cable into the USB connector of ScanSnap and plug the other end of
the cable into the USB port on your personal computer.
Insert firmly the USB-cable as far as it can go into the connector.
ATTENTION
• Use only the USB cable supplied with the Scanner. The operation with a com-
mercially available USB cable is not guaranteed.
• When connecting to a USB hub, be sure to connect the scanner to the hub
nearest your personal computer (first stage). If you connect it to a USB hub
from the second stage onwards, ScanSnap may not function correctly.
• If you connect the scanner with USB 2.0, it is required that the USB port and
the Hub are compliant with USB 2.0. The scanning speed may slow down
when you connect the scanner with USB 1.1. If your computer has the USB
2.0 compatible port, use it.
DC 16V
Seal
USB cable
USB cable

Fujitsu ScanSnap S500 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum system requirements	Windows 2000/ XP/ Vista
Scan media weight	52 - 127 g/m²
Power requirements	AC 100V - 240V, 50 / 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	2700 g
