Fujitsu Stylistic ST5000 Series User Manual

BIOS Setup Utility 12
IrDA Port Configuration Submenu Options 2
Configuration options for the IrDA Port Configuration submenu are given in Table 2-4. Note that some peripheral
interfaces are only available when using a device attached to the Tablet Dock.
Table 2-4. IrDA Port Configurations Submenu Options
Option Settings Description
Infrared Port: Enabled
Auto
Disabled
Determines whether the infrared port is active and the method used to configure
the infrared port.
• Select [Auto] to allow the BIOS or operating system to configure the port
automatically.
• Select [Enabled] to configure the I/O Address and Interrupt options manually
in BIOS setup.
• Select [Disabled] to turn off the infrared port.
Mode: IrDA
FIR
Determines which physical interface the infrared port is assigned to. Select IrDA
to use the IrDA port in Standard IR (SIR) mode (115 Kbps). Select FIR to use the
IrDA port in Fast IR mode (4 Mbps). Note: The Infrared port option must be
Enabled before this setting can be changed.
I/O Address 3F8 - 3FF
2F8 - 2FF
3E8 - 3EF
2E8 - 2EF
Determines the base I/O address and interrupt request level used for the infrared
port. The Infrared Port option must be set to [Enabled] before this setting can be
changed.
Interrupt: IRQ 3
IRQ 10
IRQ 11
Determines the interrupt number for the infrared port. Note: The Infrared port
option must be Enabled before this setting can be changed.
I/O Address: 400 - 43F
480 - 4BF
500 - 53F
580 - 5BF
Determines the base I/O address and interrupt request level used for the Fast
Infrared port. FIR Mode must be set before this setting can be changed.
DMA Channel DMA 1
DMA 3
Determines the DMA channel assigned to the infrared port when using Fast IR
mode. This option is only selectable when the Infrared Port Mode setting is FIR.
PhoenixBIOS Setup Utility
F1 Help
ESC Exit
Select Item
Select Menu
- Change Values Space
Enter Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
▲
Item Specific Help
[Disabled]
The port is disabled.
[Enabled]
The port is enabled
with user configuration.
[Auto]
Plug & Play OS
configure the port.
Exit Submenu
IrDA Port Configurations
Infrared Port: [Enabled]
Mode: [FIR]
I/O Address: [2E8-2EF]
Interrupt: [IRQ 3]
I/O Address: [400-43F]
DMA Channel: [DMA 3]
