Digitizer Specifications 3
Specifications for the two different Stylistic ST5000 Tablet PC digitizers are given in Table 3-2..
Display Specifications 3
Specifications for the Stylistic ST5000 Tablet PC display are given in Table 3-3.
Table 3-2. Digitizer Specifications
Feature Feature Sensor Unit for 12.1” LCD Sensor Unit for 10.4” LCD
Active Digitizer Type Electromagnetic digitizer Electromagnetic digitizer
Area 9.75” x 7.33” (247.8 mm x 186.3 mm) 9.26” x 5.8” (235.3 mm x 147.4 mm)
Resolution 0.01 mm 0.025 mm
Sampling Rate 133 pps 133 pps
Interface Serial interface Serial interface
Vendor Wacom Wacom
Pen Weight: 0.53 oz. (15g)
Size: 5.51” (length) x 0.35” (diameter) (140 mm x 9 mm)
Vendor: Wacom
Table 3-3. Display Specifications
Feature Specification
Transmissive XGA LCD • 12.1" diagonal TFT Color
• XGA 1024 x 768 dot composition
• Aspect ratio: 4:3
• Transmissive
• 260K colors
• Active area: 9.67” x 7.25” (245.76 mm x 184.32 mm)
• Brightness: 8 gradations
• Frontlight: FL Tube; brightness: ~20-150 Cd/m
2
Reflective XGA LCD • 10.4" diagonal TFT Color
• XGA 1024 x 768 dot composition
• Aspect ratio: 4:3
• Reflective
• 260K colors
• Active area: 8.28” x 6.21” (210.43 mm x 157.82 mm)
• Brightness: 8 gradations
• Frontlight: FL Tube; brightness: ~0 - 45 Cd/m
2
