Fujitsu Stylistic ST5000 Series User Manual

PC Card Port 43
PC Card Port 4
The PC Card socket is compliant with PCMCIA Card
standard 3.0. The table and figure below show the pin
assignments and pin locations for the PC Card port.
Table 4-8. PC Card Pin Assignments
1234
35 36 37 38 39
5
30 31 32 33 34
64
65
66 67 68
16-bit PC Card Interface
CardBus
Pin Memory-Only I/O & Memory
1 GND GND GND
2D3D3CAD0
3D4D4CAD1
4D5D5CAD3
5D6D6CAD5
6D7D7CAD7
7 CE1# CE1# CCBE0#
8 A10 A10 CAD9
9 OE# OE# CAD11
10 A11 A11 CAD12
11 A9 A9 CAD14
12 A8 A8 CCBE1#
13 A13 A13 CPAR
14 A14 A14 CPERR#
15 WE# WE# CGNT#
16 READY IREQ# CINT#
17 VCC VCC VCC
18 VPP1 VPP1 VPP1
19 A16 A16 CCLK
20 A15 A15 CIRDY#
21 A12 A12 CCBE2#
22 A7 A7 CAD18
23 A6 A6 CAD20
24 A5 A5 CAD21
25 A4 A4 CAD22
26 A3 A3 CAD23
27 A2 A2 CAD24
28 A1 A1 CAD25
29 A0 A0 CAD26
30 D0 D0 CAD27
31 D1 D1 CAD29
32 D2 D2 RFU
33 WP IOIS16# CCLKRUN#
34 GND GND GND
35 GND GND GND
36 CD1# CD1# CCD1#
37 D11 D11 CAD2
38 D12 D12 CAD4
39 D13 D13 CAD6
40 D14 D14 RFU
41 D15 D15 CAD8
42 CE2# CE2# CAD10
43 VS1# VS1# CVS1
44 RUF IORD# CAD13
45 RFU IOWR# CAD15
46 A17 A17 CAD16
47 A18 A18 RFU
16-bit PC Card Interface
CardBus
Pin Memory-Only I/O & Memory
