Furuno FAR-2318 User Manual

5. VIDEO PLOTTER OPERATION
5-5
Where [4 MARK POSITION] is set to [L/L]
1. Referring to section 5.2, select the mark type you want to use.
2. Place the cursor on the [MARK] box, at the bottom-left of the screen.
3. Spin the scrollwheel to select the appropriate mark, then left-click. [RADAR MAP]
menu appears and the first digit of the latitude is selected.
4. Referring to section 5.3, set the latitude and longitude.
5. Repeat steps 1 to 3 for multiple mark inscription, or right-click to complete the pro-
cedure.
Note: You can see the number of radar map marks, lines used, on the [RADAR MAP]
menu: [MENU]→[2 MARKS*]→[5 RADAR MAP].
*: Appears as [2 MARKS•CHART] for A/B/W-types with Radar Plotter functionality.
Radar map marks, lines
entered/total number of
marks, lines available

Furuno FAR-2318 Specifications

General

Brand	Furuno
Model	FAR-2318
Category	Marine Radar
Language	English
