Furuno FMD3100 User Manual

APPENDIX 2 ROD TERMINALS
AP-5
*: Pin #1 and 5: no cable connection. However the jumper connection is necessary between #1
and 2 and #5 and 6 depending on the input specification.
*: Pin #1 and 5: no cable connection. However the jumper connection is necessary between #1
and 2 and #5 and 6 depending on the input specification.
Connector # Pin # Signal name Rod terminal to use Connected cable
J5*
1 DV12V_OUT5
AI 1-6 RD (red) MPYC-12
2 DIGI_IN5
3 DIGI_RTN5
4GND
5 DC12V_OUT6
6 DIGI_IN6
7 DIGI_RTN6
8GND
Connector # Pin # Signal name Rod terminal to use Connected cable
J6*
1 DV12V_OUT7
AI 1-6 RD (red) MPYC-12
2 DIGI_IN7
3 DIGI_RTN7
4GND
5 DC12V_OUT8
6 DIGI_IN8
7 DIGI_RTN8
8GND
