Furuno FMD3100 User Manual

APPENDIX 2 ROD TERMINALS
AP-6
MC-3030D, MC-DOUT Board (24P0117)
Connector # Pin # Signal name Rod terminal to use Connected cable
J1
1 24V_IN AI 0.34-6 TQ (blue)
MC1.5-W-Lxxx
2 24V_GND
3 MODBUS-A AI 0.14-8 GY (gray)
4 MODBUS-B
5GND
Connector # Pin # Signal name Rod terminal to use Connected cable
J2
1 24V_OUT AI 0.34-6 TQ (blue)
MC1.5-W-Lxxx
2 24V_GND
3 MODBUS-A AI 0.14-8 GY (gray)
4 MODBUS-B
5GND
Connector # Pin # Signal name Rod terminal to use Connected cable
J3
1A1
AI 1-6 RD (red) MPYC-12
2COM1
3B1
4A2
5COM2
6B2
Connector # Pin # Signal name Rod terminal to use Connected cable
J4
1A3
AI 1-6 RD (red) MPYC-12
2COM3
3B3
4A4
5COM4
6B4
Connector # Pin # Signal name Rod terminal to use Connected cable
J5
1A5
AI 1-6 RD (red) MPYC-12
2COM5
3B5
4A6
5COM6
6B6
Connector # Pin # Signal name Rod terminal to use Connected cable
J6
1A7
AI 1-6 RD (red) MPYC-12
2COM7
3B7
4A8
5COM8
6B8
