Receiver switch

Receiver battery

Charging port/

DSC connector



In S.BUS

use

(8/SB)

S.BUS not

using it

(CH1-8)

(7/B)

Servos



























Receiver and servos connection

Connect the receiver and servos in accordance with the connection diagram shown below. Always read

[Precautions when mounting the receiver and servos] and [Before using]. When mounting the receiver and

servos to the fuselage, connect the necessary points in accordance with the kit instruction manual.



Connect the servos to match the fuselage used.
