GE LOGIQ P5 Service Manual

GE HEALTHCARE
DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
Section 3-3 - Receiving and Unpacking the Equipment 3-7
Section 3-3 Receiving and Unpacking the Equipment (cont’d)
4.) Remove the three PLASTIC JOINTs from the OUTER SLEEVE.
5.) Remove the OUTER SLEEVE.
Figure 3-5 Removing Plastic Joints and Sleeves
Plastic Joint
Outer Sleeve
Palette Assy
