GE
D
IRECTION GB091046, REVISION 2 VIVID E9 / VIVID E7 BT’13 SERVICE MANUAL
3 - 18 Section 3-5 - Completing the setup
3-5-3 Electrical specifications
3-5-3-1 Verification of the system’s voltage setting
Verify that the mains voltage specified for the unit is available on-site.
The voltage setting for the unit is found on a label near the Mains Power Circuit Breaker on the rear of
the system.
3-5-3-2 Electrical specifications for VIVID E9 / VIVID E7
In the table below, the electrical specifications for VIVID E9 and VIVID E7 includes monitor and on board
peripherals.
The current drain will vary depending on the mains voltage.
• At 230 VAC the current may be up to 5 A.
• At 100 VAC the current may be up to 12 A.
CONNECTING A VIVID E9 / VIVID E7 UNIT TO THE WRONG VOLTAGE LEVEL WILL
MOST LIKELY DESTROY THE UNIT.
Figure 3-2 Mains Voltage Rating label
Table 3-12 Electrical specifications for VIVID E9 / VIVID E7
PART NUMBER DESCRIPTION VOLTAGE TOLERANCES
POWER
CONSUMPTION FREQUENCY
XDclear (S/W v113.x)
GB000070
Vivid E9 4D Expert Option 17 inch LCD
100-230 VAC ±10% 1100 W 50/60 Hz
GB000080
Vivid E9 4D Expert Option 19 inch LCD
GB000075
Vivid E9 2D 17 inch LCD
GB000085
Vivid E9 2D 19 inch LCD
GB000090
Vivid E9 Pro configuration 17 inch LCD
GB000095
Vivid E9 Pro configuration 19 inch LCD
GB000099
Vivid E7 'XDclear' 'Pro configuration' 17'
GB000100
Vivid E7 'XDclear' 'Pro configuration' 19'
M o d e l :
G A 3 1 4 3 2 3 0 1
V A C
W
H z
V i v i d E 9
R E F
R E F
H 4 5 5 4 1 S D
# 1
# 2
G A 0 0 0 1 0 0
1 1 0 0
5 0 / 6 0
1 0 0 - 2 3 0
VERIFY THAT THE VOLTAGE ON THE
LABEL CORRESPONDS TO THE SITE’S
MAINS VOLTAGE
