The service manual provides installation and service information for the VIVID E9 / VIVID E7 ultrasound
scanning unit. It is divided in 10 chapters as shown below, in Table 1-1 "Contents in this service manual"
on page 1-2.
1-2-1 Contents in this manual
The service manual is divided into ten chapters.
In the beginning of the manual, before chapter 1, you will find the language policy for GE’s service
documentation, legal information, a revision overview and the Table of Contents (TOC).
An Index has been included after chapter 10.
Table 1-1 Contents in this service manual
CHAPTER
NUMBER
CHAPTER TITLE DESCRIPTION
1
Introduction Contains a content summary and warnings.
2
Site preparations
Contains pre-installation requirements for the VIVID E9 / VIVID E7.
3
System setup
Contains installation procedure with installation checklist.
4
General procedures and Functional
checks
Contains functional checks that must be performed as part of the
installation, or as required during servicing and periodic
maintenance.
5
Components and functions (theory)
Contains block diagrams and functional explanations of the
electronics.
6
Service adjustments
Contains instructions on how to make any available adjustments to
the VIVID E9 / VIVID E7.
7
Diagnostics / troubleshooting
Provides procedures for running and diagnostic or related routines
for the VIVID E9 / VIVID E7.
8
Replacement procedures
Provides disassembly procedures and reassembly procedures for all
changeable FRU.
9
Renewal parts
Contains a complete list of replacement parts for VIVID E9 /
VIVID E7.
10
Care & maintenance
Provides periodic maintenance procedures for VIVID E9 / VIVID E7.
N/A
Index A quick way to the topic you’re looking for.
