GE
D
IRECTION GB091046, REVISION 2 VIVID E9 / VIVID E7 BT’13 SERVICE MANUAL
Chapter 7 - Diagnostics / troubleshooting 7 - 3
7-3-3 How to Release the Top Console when power is unavailable
Question:
How to release the Z brakes (Up/Down) when without power?
Answer:
There is a lever behind the openings in the Rear Cover. Press the lever to the right to release the X/Y
brakes. At the same time, push the Upper Console down. If you stop to press the lever, the Z brakes
engage.
For more information, see: 4-2-3-6 "Moving the Top Console up or down when Power is OFF" on page
4-13.
Question:
How to release the XY brakes when without power?
Answer:
See the instructions in: 4-2-3-5 "Manually releasing the XY Lock" on page 4-12.
