8-6-2 Replacing the 19” LCD Monitor assembly
8-6-2-1 Manpower
One person, 15 minutes
8-6-2-2 Tools
For tools needed, please refer to: 8-2-5 "Tools needed for servicing VIVID E9 / VIVID E7" on page 8-5.
8-6-2-3 Preparations
When preparing for the replacement, you must perform the following steps:
1.) Power down the VIVID E9 / VIVID E7.
2.) Move the User Interface (Top Console) to its lower position.
3.) Disconnect the Mains Power Cable from the wall outlet.
4.) Disconnect all probes and I/O cabling.
8-6-2-4 Remove the 19” LCD Monitor Cables Cover
A cover at the rear side of the LCD Monitor assembly covers the two cables to the monitor. To get
access to the cable connectors, remove the Cable Cover.
Follow these steps to remove the Cable Cover:
1.) For easy access, tilt the LCD Monitor forward to horizontal position.
ENERGY CONTROL AND POWER LOCKOUT FOR VIVID E9 / VIVID E7.
WHEN SERVICING PARTS OF THE SYSTEM WHERE THERE IS EXPOSURE TO
VOLTAGE GREATER THAN 30 VOLTS:
1. FOLLOW LOCK OUT/TAG OUT PROCEDURES.
2. TURN OFF THE BREAKER.
3. UNPLUG THE VIVID E9 / VIVID E7.
4. MAINTAIN CONTROL OF THE POWER PLUG.
5. WAIT FOR AT LEAST 20 SECONDS FOR CAPACITORS TO DISCHARGE, AS THERE ARE NO TEST POINTS TO
VERIFY ISOLATION. THE AMBER LIGHT ON THE OP PANEL ON/OFF BUTTON WILL TURN OFF.
BEWARE THAT THE MAIN POWER SUPPLY AND BACK END PROCESSOR MAY BE ENERGIZED EVEN IF THE POWER
IS TURNED OFF WHEN THE CORD IS STILL PLUGGED INTO THE AC OUTLET.
