GE
D
IRECTION GB091046, REVISION 2 VIVID E9 / VIVID E7 BT’13 SERVICE MANUAL
9 - 48 Section 9-12 - Back End Processor (BEP) Spare Parts
7.
Graphics Adapter for BEP6.0 with 4D 066E0362
NVIDIA QUADRO 410
Used on VIVID E9s with BEP6 and 4D.
1NY
8.
BEP6.X Video By-Pass Board 5433408-90 1NY
9.
"Intel® HD Graphics" and "Intel®
Graphics Media Accelerator". - BEP6
N/A Included on the BEP6’s Motherboard 1 N N
10.
Digital Video Recorder Circuit Board 5135840
OPTION
May be used with all BEPs
1 N Y
11.
All BEP6 cables See Section 9-17-6-1 "BEP6 cables" on page 9-63
Table 9-23 BEP6 Spare Parts (cont’d) sheet 2 of 2
ITEM PART NAME PART NUMBER DESCRIPTION QTY CRU FRU
To Next Page
