User Guide Electrical Line Shaft for ADV200 Page 45 of 72
5.14 POSITION ERROR Menu
The POSITION ERROR menu contains parameters for monitoring and managing a following error by the slave
shaft with respect to the master.
The position error control diagram is shown in the chapter “CONTROL DIAGRAMS” Figure 37. Position error.
The system generates a Warning signal and then an Alarm if the error exceeds the user-programmable
thresholds.
When a Warning is generated, a signal is given but the drive maintains its operating state.
If an Alarm trips, a signal is given and the drive is immediately disabled. The signal persists as long as the Els
Engage mon command remains On.
To restart the system, the alarm must be reset (after the Els Engage command is removed).
Parameter Name
User type
Value
Unit
Min
Max
Access
11192 Els Pos Warning Thr
Float
180
u.u.
0
1e6
RW
Following error Warning threshold.
11194 Els Pos Warning Time
Unsigned short
100
ms
0
5000
ERW
Hold time beyond Els Pos Warning Thr threshold before signaling Warning state Els Pos Warn mon.
11196 Els Pos Warn dest
Enumerative
Null (def)
Pad from 1 to 16
-
-
-
ERWZ
Selector of destination of state monitor Els Pos Warn mon.
11198 Els Pos Alarm Thr
Float
360
u.u.
0
1e6
RW
Following error Alarm threshold.
11200 Els Pos Alarm Time
Unsigned shor
100
ms
0
5000
ERW
Hold time beyond Els Pos Alarm Thr threshold before signaling Alarm state Els Pos Alarm mon.
11202 Els Pos Alarm dest
Enumerative
Null (def)
Pad from 1 to 16
-
-
-
ERWZ
Selector of destination of state monitor Els Pos Alarm mon.
12134 Els Pos Warn mon
Boolean
-
-
-
-
R
Monitor of following error Warning state.
12136 Els Pos Alarm mon
Boolean
-
-
-
-
R
Monitor of following error Alarm state.
