RT250 - REFERENCE
METRIC BOLT TORQUE GUIDE
Use these torque values when tightening hardware—excluding: lock nuts, thread-forming, self-tap-
ping, and metal screws—unless otherwise specified.
M5 4.1 (5.5) 6 (8) 7 (10) 4 (5) 5 (7)
M6 7 (10) 10 (14) 13 (17) 6.3 (8.5) 9 (12)
M8 18 ( 25) 26 (35) 31 (42) 15 (20) 22 (30)
M10 33 (45) 48 (65) 59 (80) 30 (40) 44 (59)
M12 64 (87) 81 (110) 108 (147) 51 (69) 74 (100)
M14 100 (135) 133 (180) 170 (230) 81 (110) 118 (160)
M16 155 (210) 203 (275) 258 (350) 125 (170) 184 (250)
M18 207 (280) 302 (410) 354 (480) 181 (245) 254 (345)
M20 302 (410) 420 (570) 509 (690) 251 (340) 361 (490)
M22 406 (550) 575 (780) 686 (930) 339 (460) 487 (660)
M24 524 (710) 738 (1000) 878 (1190) 435 (590) 620 (840)
M27 767 (1040) 1092 (1480) 1305 (1770) 642 (870) 922 (1250)
M30 1047 (1420) 1482 (2010) 1770 (2400) 885 (1200) 1254 (1700)
Metric
Coarse-Pitch
Thread—(DRY)
8.8 10.9 12.9 8.8
10.9
DIN 912, DIN 931, DIN 933, etc... DIN 7984
All torque values are in Foot-Pounds and Newton Meters (Nm).
M8X1.0 18 (25) 27 (37) 32 (43) 16 (22) 24 (32)
M10X1.0 37 (50) 55 (75) 65 (88) 32 (43) 48 (65)
M10X1.25 36 (49) 52 (71) 61 (83) 31 (42) 46 (62)
M12X1.25 64 (87) 96 (130) 111 (150) 55 (75) 81 (110)
M12X1.5 61 (83) 92 (125) 107 (145) 53 (72) 77 (105)
M14X1.5 100 (135) 148 (200) 173 (235) 89 (120) 129 (175)
M16X1.5 155 (210) 229 (310) 266 (360) 133 (180) 195 (265)
M18X1.5 232 (315) 332 (450) 391 (530) 199 (270) 284 (385)
M20X1.5 325 (440) 465 (630) 538 (730) 277 (375) 391 (530)
M22X1.5 435 (590) 620 (840) 723 (980) 369 (500) 524 (710)
M24X2.0 546 (740) 789 (1070) 922 (1250) 465 (630) 664 (900)
M27X2.0 811 (1100) 1143 (1550) 1328 (1800) 679 (920) 959 (1300)
M30X2.0 1106 (1500) 1586 (2150) 1844 (2500) 959 (1300) 1364 (1850)
Metric
Fine-Pitch
Thread—(DRY)
8.8 10.9 12.9 8.8
10.9
DIN 912, DIN 931, DIN 933, etc... DIN 7984
All torque values are in Foot-Pounds and Newton Meters (Nm).
M6-1 6 (8) 8 (11) 10 (14)
M8-1.25 14 (19) 20 (27) 24 (33)
M10-1.5 28 (38) 39 (53) 47 (63)
M12-1.75 48 (65) 68 (91) 82 (111)
M14-2 77 (103) 108 (146) 131 (177)
M16-2 118 (160) 166 (224) 200 (271)
Metric
Coarse-Pitch
Thread—(OILED)
8.8 10.9 12.9
DIN 912, DIN 931, DIN 933, etc...
All torque values are in Foot-Pounds and Newton Meters (Nm).
