Gehl RT250 User Manual

Printed in U.S.A. 87 913364/BP0314
RT250 - LOADER ARM
ATTACHMENT BRACKET - MANUAL (STANDARD) / BUCKET
01 274521 WELDMENT, QUICK ATTACH 1
02 650731 CS 3/8 x 3-1/2 C5ZY 2
03 271366 PIN (attaches tilt cylinder) 2
04 067847 HLN INST 3/8 CZY 2
05 653054 HJN HVY 3/4 C5ZY 2
06 650649 CS 3/4 x 2 C5ZY 2
07 50280004 CS 1/2 x 1-1/4 C5ZY SP 2
08 274526 WASHER 35/64 2
09 081380 CS FL LOCK 5/16 x 3/4 C5ZY 6
10 50302150 PIN (attaches to loader arm) 2
11 654009 FW 1/2 AWZY 2
12 50280006 CS 1/2 x 2-1/2 C5ZY SP 2
13 570002 FITTING, GREASE 1/8 PTF 2
14 138752 HANDLE PIVOT 1
15 270675 HANDLE 1
16 137379 PIN LINK 1
17 50280005 CS 3/8 x 3-1/2 C8ZY SP 1
18 088912 FW 13/32 ZY 1
19 137167 LINK, ADJUSTABLE END 2
20 137158 LINK, SPRING STOP 2
21 137385 SPRING PIN 2
22 H8049 SPRING 2
23 137164 LINK, SPRING SLIDE 2
24 655006 COTTER PIN 1/8"x1" Z 2
25 50350090 PIN, CLEVIS 7/16"x1-5/8" ZY 2
26 137386 PIN 2
27 137170 LATCH PIN 2
28 137168 PIN LINK 2
29 137169 LATCH LINK 2
30 50302097 SCREW/SHOULDER 3/8"X1-3/4" 8 2
31 210-31017 LN FL CTR 5/16 CFZY 2
32 270064 QUICK ATTACH PIN ASSEMBLY 2
(includes items 24-31)
33 275914 SHIM 4
34 570014 GREASE ZERK 1/4 ST 2
35 50302153 BUSHING, STEPPED 3/4 x 1 2
Item
No. Part No. Description Qty.
Item
No. Part No. Description Qty.
36 810922 BUCKET, 84” HD D/C 1
(Available only through the Whole Goods Department
—includes all items shown)
37 136358 CUTTING EDGE, 3/4"x8"x83.878" * 1
Item
No. Part No. Description Qty.
36
37
39
38
Item
No. Part No. Description Qty.
38 653026 HN 3/4 C2ZY * 7
39 651351 PLOW BOLT 3/4” x 2-1/2” * 7
* The cutting edge and hardware are optional and are not
included with the bucket.
NOTE: Complete buckets
can only be purchased
from the Whole Goods
Department.
