Gehl RT250 User Manual

Printed in U.S.A. 81 913364/BP0314
RT250 - TRACKS
TRACK DRIVE MOTOR AND SPROCKET
01 273650 ST-LN MJ06-MORB06 2
02 271709 ST-LN MJ08-MORB08 1
03 50302378 ST MC20-MORB12-S-SP 2
04 274423 MOTOR, DRIVE 1273cc W/FLANGE 1
05 274604 SHCS M14-2x50 C12.9PSP DIN912 12
06 270322 SPROCKET, DRIVE 1
07 274603 SHCS M16-2X45 C12.9 P SP D912 8
Item
No. Part No. Description Qty.
2
1
3
3
1
4
5
6
7
Drive motor is
also shown on
pages 76
and 82.
NOTE: Quantities shown are for one drive
motor and one sprocket assembly. When order-
ing parts, be aware that the machine uses two
drive motors and sprocket assemblies, one on
each side. Refer to next page for component
parts.
