Use these torque values when tightening hardware—excluding: lock nuts, thread-forming, self-tap-
ping, and metal screws—unless otherwise specified.
NOTE: All torque values are in foot-pounds (lb.-ft.), except those marked with asterisks (*), which
are in inch-pounds (lb.-in.). To convert lb.-ft. to Newton Meter (Nm)—metric—torque values, multi-
ply the lb.-ft. value by 1.355, or for inch pounds, multiply the lb.-in. value by 0.113.
* Value shown is in pound-force inch (lb.-in.)—inch pounds.
RT250 - REFERENCE
SAE BOLT TORQUE GUIDE
8-32 19* 14* 30* 22* 41* 31*
8-36 20* 15* 31* 23* 43* 32*
10-24 27* 21* 43* 32* 60* 45*
10-32 31* 23* 49* 36* 68* 51*
1/4-20 66* 50* 9 75* 12 9
1/4-28 76* 56* 10 86* 14 10
5/16-18 11 9 17 13 25 18
5/16/24 12 9 19 14 25 20
3/8-16 20 15 30 23 45 35
3/8-24 23 17 35 25 50 35
7/16-14 32 24 50 35 70 55
7/16-20 36 27 55 40 80 60
1/2-13 35 35 75 55 110 80
1/2-20 40 40 90 65 120 90
9/16-12 55 55 110 80 150 110
9/16-18 60 60 120 90 170 130
5/8-11 75 75 150 110 220 170
5/8-18 85 85 180 130 240 180
3/4-10 130 130 260 200 380 280
3/4-16 150 150 300 220 420 320
7/8-9 125 125 430 320 600 460
7/8-14 140 140 470 630 660 500
1-8 190 190 640 480 900 680
1-14 210 210 710 530 1000 740
Grade 2
Dry Oiled
Unified
National
Thread
Grade 5
Dry Oiled
Grade 8
Dry Oiled
