DenOptix QST
032-0265-EN Rev 13-10
Disposable Barrier Envelopes
1. The front of the barrier envelope is blue. This is the side that should face the
X-ray tube.
2. Barrier envelope adhesive strip. When this is removed, the envelope can be
sealed and provides protection from cross-contamination.
Computer Requirements
Minimum Computer
Requirements
Recommended
CPU Speed 800 MHz Pentium 4 2.4 GHz
Operating system Microsoft® Windows® 2000 /
XP Pro SP2
Microsoft® Windows® XP Pro
SP2
RAM 128 MB 256+ MB
Hard Drive 6 GB 40+ GB
1
USB port USB 2.0 USB 2.0
Monitor dot pitch S-VGA with 0.25mm/0.26mm
dot pitch
S-VGA with 0.25mm/0.26mm
Video Display Adapter 4 MB RAM, 800 x 600 display,
true color
8+ MB RAM, 1024x768 true
color
Keyboard, Mouse Standard Standard
Backup Device Highly recommended
Printer Recommended (see appendix
C)
Front (Blue)
Back (Clear)
2
1
