2.4 Commissioning Procedure
The following procedure must be carried out by a trained installation engineer
before the machine can be used for the first time.
1. Ensure that the electrical and water services to the machine are connected
correctly and turned on. Ensure that the waste tray is fitted correctly to
the machine. Open the front door of the machine and swing the cup turret
assembly out of the machine.
2. All Models: Rotate soluble ingredient canister outlets to upright position
and remove the canisters - DO NOT place ingredient canisters on the
floor. Remove the canister lids.
Fill the canisters with the correct ingredients, re-fit the lids and re-fit
canisters into machine ensuring that they are returned to their correct
positions. Rotate the canister outlets to their correct operating positions.
Freshbrew Models: Fill freshbrew ingredient canisters with freshbrew
tea and coffee ingredient and refit to machine.
B2C Models: Release the clips securing the
bean container cover as shown in the
photograph. Carefully lift the cover from the
container. DO NOT place the cover on the
floor.
Fill the container with fresh coffee beans. The
container has a capacity of approximately 1.8
kgs. Refit the cover ensuring that the clips are
located correctly.
N.B. To maintain optimum drink quality, Crane Merchandising Systems
recommend that the bean container is replenished on a daily basis.
3. Load the cup turret. Fill the tubes with the
correct size cups for the type of cup catcher
fitted to the machine. Allow the cups to drop
into the tubes directly from the packaging. DO
NOT TOUCH THE CUPS WITH YOUR
HANDS.
Important: Do not fill the tube directly above
the cup dispense position. Allow the cup turret
motor to rotate a full tube to the cup dispense
position. Rotating the cup turret by hand will damage the mechanism.
Note: If paper cups are being loaded, each pack of cups must first be
inspected for damage to the cup rims. Damaged cups must not be used.
11
Operators Manual
