GWN7000 User Manual
Version 1.0.6.28
Figure 70: Traffic Rules Settings
Refer to below table for each tab, when editing or creating a traffic rule:
Table 38: Firewall Traffic Rules
Name
Specify a name for the traffic rule.
Enabled
Check to enable this rule.
IP Family
Select the IP version, three options are available: IPv4, IPv6 or Any.
Source Group
Select a WAN interface or a LAN group for Source Group, or select All.
Protocol
Select one of the protocols from dropdown list or All, available options
are: UDP, TCP, TCP/UCP, UDP-Lite, ICMP, AH, SCTP, IGMP and All.
Source IP Address
Set the Source IP address, it can be an IPv4 or IPv6 address.
Source Port(s)
Set the source port number. Or port range.
Source MAC address
Set the Source MAC address.
Destination IP
Set the destination IP address, it can be an IPv4 or IPv6 address.
Destination Port(s)
Set the destination’s port(s).
Firewall Action
Select which action to perform for the given traffic rule, 3 options are
available: Accept, Reject or Drop.
