Governors
4
L / M . . / 07.96
L 30. H .L 30
* When driving a generator at 1500 and 1800 rpm. governor weights with Ident No. 036 349 00
were used from 1979 to 1982. They are identifiable by a „G“ stamped on the end or a white
spot.
If needed, renew these governor weights as a complete set. since governor weights with
Ident-No. 035 729 00 are now installed for all running-speed ranges.
L 40. M 40 with injection pumps PFR 1K 80A 477
* Identifiction: windings are slightly grounded at circumference.
L 31. M 31. L 40. M 40 with injection pumps PFR 1K 90A 498, L 41 and M 41
* With this governor spring the spacing ring ident No. 037 729 00 is deleted (Fig. 48a/50)
Speed Application
Governor spring
Governor weight
Ident-No.
Ident-No.
Wire
∅∅
mm
≤ 2300
Normal operation
036 012 01 3.0
035 729 00
> 2300
035 744 01 3.2
1500 *
Generator drive
036 014 01 2.5
1800 *
036 013 01 2.6
3000
035 744 01 3.2
Speed Application
Governor spring
Governor weight
Ident-No.
Ident-No.
Wire
∅∅
mm
≤ 2300
Normal operation
036 012 01 3.0
035 729 00
> 2300
035 744 01 3.2
1500
Generator drive
037 739 00 2.5*
1800
036 013 01 2.6
3000
035 744 01 3.2
Speed Application
Governor spring
Governor weight
Ident-No.
Ident-No.
Wire
∅∅
mm
≤ 2300
Normal operation
036 012 01 3.0
035 729 00
> 2300
035 744 01 3.2
1500
Generator drive
038 670 00 2.3*
1500
036 014 01 2.5
1800
036 013 01 2.6
3000
035 744 01 3.2
