Hayward Easy Temp ECP 06 User Manual

2
2. TECHNICAL SPECIFICATIONS
2.1 Technical data for the swimming pool heat pump unit
Model
EASY TEMP
ECP 06 ECP 08 ECP 11 ECP 13 ECP 15
Heating capacity*
kW
BTU/h
5.5
18785
8
27322
11
37566
13.5
46105
15
51228
Electrical power rating kW 1.17 1.8 2.43 3 3.13
Operating current* A 5.19 7,91 11,81 14,5 16
Electrical connection
V
Ph/Hz
230 V

1 / 50Hz
230 V 
1 / 50Hz
230 V 
1 / 50Hz
230 V 
1 / 50Hz
230 V 
1 / 50Hz
Fuse rating aM A 8 aM 10 aM 16 aM 20 aM 20 aM
D-curve circuit breaker A 8 D 10 D 16 D 20 D 20 D
Number of compressors 11111
Type of compressor Rotary Rotary Rotary Scroll Scroll
Number of fans 11111
Fan power W 50 120 120 120 120
Fan rotation speed RPM 770 850 850 850 850
Fan direction Horizontal Horizontal Horizontal Horizontal Horizontal
Sound pressure level (at 1
metre)
dB(A) 47 51 54 56 56
Hydraulic connection mm 50 50 50 50 50
Water flow rate m
3
/h 2.3 3.0 4.5 5.3 6.6
Water pressure drop (max) kPa 5.4 8.9 19.2 5.2 39.9
Unit net dimensions (L/W/H) mm 895/375/545 1035/415/650 1035/415/650 1136/440/870 1136/440/870
Unit shipping dimensions
(L/W/H)
mm 970/430/710 1120/480/810 1180/480/810 1230/510/1020 1230/510/1020
Unit net weight/shipping
weight
kg 45/56 54/68 60/74 95/115 117/128
* Value +/- 5% in the following conditions: Outside temperature = 24°C (75°F)/RH=62%/Pool temperature=27°C (80°F)
