HIKVISION DS-2TD4166-50-V2 User Manual

User Manual of Thermal Bi-spectrum Network Speed dome
© Hikvision
31
7. Click OK to save all the patrol settings.
 Calling a Patrol:
In the PTZ control panel, select a defined patrol from the list and click to call the patrol, as
shown in Figure 4-10.
Figure 4-10 Calling a Preset
Figure 4-11 Patrol Path 8
4.4.8 Setting / Calling a Pattern
Purpose:
A pattern is a memorized series of pan, tilt, zoom, and preset functions. It can be called on the
pattern settings interface. There are up to 4 patterns for customizing.
Pattern function varies depending on speed dome models.
 Setting a Pattern:
Steps:
1. In the PTZ control panel, click to enter the pattern settings interface.
2. Select a pattern number from the list as shown in Figure 4-12.
Figure 4-12 Patterns Settings Interface
