HIKVISION DS-K1T342 Series User Manual

Chapter 4 Wiring
You can connect the RS-485 terminal with the RS-485 card reader, connect the NC/NO and COM
terminal with the door lock, connect the SEN and GND terminal with the door contact, the
BTN/GND terminal with the exit buon, and connect the Wiegand terminal with the Wiegand card
reader or the access controller.
If connect the WIEGAND terminal with the access controller, the face recognion terminal can
transmit the authencaon informaon to the access controller and the access controller can
judge whether to open the door or not.
Note
●
If cable size is 18 AWG, you should use a 12 V power supply. And the distance between the
power supply and the device should be no more than 20 m.
●
If the cable size is 15 AWG, you should use a 12 V power supply. And the distance between the
power supply and the device should be no more than 30 m.
●
If the cable size is 12 AWG, you should use a 12 V power supply. And the distance between the
power supply and the device should be no more than 40 m.
●
The external card reader, door lock, exit buon, and door magnec need individual power
supply.
4.1 Terminal Descripon
The terminals contains power input, RS-485, Wiegand output, and door lock.
The descripons of the terminals are as follows:
Table 4-1 Terminal Descripons
Group No. Funcon Color Name Descripon
Group A A1 Power Input Red +12 V 12 VDC Power
Supply
A2 Black GND Ground
Group B B1 RS-485 Yellow 485+ RS-485 Wiring
B2 Blue 485-
B3 Black GND Ground
Group C C1 Wiegand Green W0 Wiegand
Wiring 0
DS-K1T342 Series Face Recognion Terminal User Manual
20
