iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual
UM iDS-2CD7xxG0-xxxxx 021021NA 33
• User Name and Password: The FTP user should have the permission to upload pictures.
If the FTP server supports picture uploading by anonymous users, you can check Anonymous to
hide your device information during uploading.
• Directory Structure: The saving path of snapshots in the FTP server.
• Picture Filing Interval: For better picture management, you can set the picture filing interval from 1
day to 30 days. Pictures captured in the same time interval will be saved in one folder named for
the beginning date and ending date of the time interval.
Picture Name
Set the naming rule for captured pictures. You can choose Default in the drop-down list to use the default
rule, that is, IP address_channel number_capture time_event type.jpg (e.g.,
10.11.37.189_01_20150917094425492_FACE_DETECTION.jpg). Or you can customize it by adding a Custom
Prefix to the default naming rule.
1. Check Upload Picture to enable uploading snapshots to the FTP server.
2. Check Enable Automatic Network Replenishment.
Upload to FTP/Memory Card/NAS in Linkage Method and Enable Automatic Network
Replenishment should both be enabled simultaneously.
3. Click Test to verify the FTP server.
4. Click Save.
Set NAS
Take network server as network disk to store the record files, captured images, etc.
Before You Start
Get the IP address of the network disk first.
Steps
1. Go to NAS setting page: Configuration → Storage → Storage Management → Net HDD.
2. Click HDD No. Enter the server address and file path for the disk.
• Server Address: The IP address of the network disk.
• File Path: The saving path of network disk files.
Mounting Type
Select file system protocol according to the operation system.
Enter user name and password of the net HDD to guarantee the security if SMB/CIFS is selected.
1. Click Test to check whether the network disk is available.
